Grundfos CMBE TWIN 3-93 I-U-C-C-D-A Variable Speed Pump 99282855

Grundfos CMBE TWIN 3-93 I-U-C-C-D-A Variable Speed Constant Pressure Pump 99282855 The Grundfos CMBE TWIN Booster is a compact two-booster system for water supply in domestic and commercial applications. The integrated speed controller allows the CMBE Booster to maintain constant pressure in the pipe system. A pressure sensor monitoring changes in the water consumption will signal the speed controller to change the motor speed. This way performance is adjusted according to the new state, thus running in cascade multi pump. The cascade control ensures that the performance of the CMBE Booster is automatically adapted to consumption by switching pumps on or off and by changing the speed of the pumps in operation. The system thus runs as energy-efficiently as possible with a limited number of pumps. The CMBE-TWIN Booster is very easy to install. It has UL approval. The CME Booster consists of 2 units of CMBE Booster which each include: CME pump with integrated frequency converter 5-way valve expansion tank pressure gauge Features Cascade Multi Pump Operation Automatic Pump Alteration Constant pressure control Pipe Filling Robust, Stainless steel Easy Installation Dry Run protection Applications Apartment Buildings Schools Small hotels Office Buildings Agriculture • Constant pressure via integrated speed control • Cascade control and pump alternation • Dry-running protection • Compact • Robust, stainless steel design • Easy installation • Low energy consumption • Noise level below 55 dB(A) and even lower at controlled speed Thermal protection CME Booster pumps require no external motor protection. The MGE motor incorporates thermal protection against slow overloading and blocking. Grundfos CMBE Booster is mainly used for domestic and light commercial water supply or booster systems. NB: Max. 1 m, including suction-pipe pressure loss at a liquid temperature of 20 °C. (not self-priming) Components (per pump): – CME pump with integrated frequency converter with all parts in contact with the liquid constructed from stainless steel (AISI 304) – 5-way tee with non return valve – Expansion vessel 2 litre – Pressure sensor and pressure gauge – Power cable – 1.5 m length with plug Motor / power: 1500W Max. flow: 250T/min Head: 102m Suction Lift: 1m Inlet: 1″F / 25mm Outlet: 1″F / 25mm Pressure: 1020kPa Body: 304 Stainless Steel Diffuser: Technopolymer Impeller:304 Stainless Steel Pump Shaft: 304 Stainless Steel Mechanical Seal : Carbon with resin/ceramic Start pressure: Integrated Frequency converter Tank Volume: 2LT 2LT Liquid temperature: 0°C to 60°C Ambient temperature: 0°C to 55°C Supply voltage: 1 x 240 Volt 50 Hz System pressure: Maximum 10 bar Enclosure class: Suitable for covered installation (IP55) Note 1: P2 & Rated Current (In [A]) is per pump Warranty on pump: 2 Years Weight: 52.1kg Code: 99282855
